Keel optimization

 Post Reply Post Reply Page  12>
Author
Message
Mary400e View Drop Down
Sub Lieutenant
Sub Lieutenant


Joined: 05 December 2016
Location: Copenhagen
Status: Offline
Points: 17
Post Options Post Options   Thanks (0) Thanks(0)   Quote Mary400e Quote  Post ReplyReply Direct Link To This Post Topic: Keel optimization
    Posted: 22 September 2017 at 12:17

Hi

I'm considering an optimization of the keel, to improve the upwind performance.

Do anyone have the VPP scheme for the L-shape and the new T-shape (iron).

I have the original lead keel (L-shape).



BR Jesper


Back to Top
iemand View Drop Down
Vice Admiral
Vice Admiral
Avatar

Joined: 13 February 2004
Location: Germany
Status: Offline
Points: 838
Post Options Post Options   Thanks (0) Thanks(0)   Quote iemand Quote  Post ReplyReply Direct Link To This Post Posted: 22 September 2017 at 15:07
 I talked to J&V the other day about the keel differences (it was about the Hanse 470) He said that the L-Shape iron/lead keel will always have better performance than the iron T-Shape keel. The wetted surface of the T-Keel is much higher.
A Lead T-Keel might be different but not the iron standard T-keel.

BR Thomas
Hanse 312 MJ 2004 - Hanse 370e MJ 2007
Back to Top
H8jer View Drop Down
Rear Admiral
Rear Admiral


Joined: 14 September 2010
Location: Denmark
Status: Online
Points: 593
Post Options Post Options   Thanks (0) Thanks(0)   Quote H8jer Quote  Post ReplyReply Direct Link To This Post Posted: 23 September 2017 at 13:01
Hi

More on keel shapes - paper from Swedish research:
//
The results as analyzed throughout chapter 3 to 5 has
consistently shown that for both these cases the T-bulbed keel performs best of the bulbed keels, and
also better than the fin keel in higher wind speeds.
//


I would think it is a waist of time and money going for a new keel.
What about the sails? If you're still using self-tacker, it would be more wise to get a headsail with overlap.

/H8jer


Edited by H8jer - 23 September 2017 at 13:02
Hanse 370#480 30HP 3-cabin
Back to Top
Mary400e View Drop Down
Sub Lieutenant
Sub Lieutenant


Joined: 05 December 2016
Location: Copenhagen
Status: Offline
Points: 17
Post Options Post Options   Thanks (0) Thanks(0)   Quote Mary400e Quote  Post ReplyReply Direct Link To This Post Posted: 25 September 2017 at 12:21

Hi

Thanks for the reply’s. I have looked in the provided technical documentation (Swedish research), very interesting.

Regarding the difference between L and T-shape keels and what is possible/realistic will I still try to get some more information (VPP) about the performance of the T-keel. Another solution is to modify/improve the L-keel to get a more optimal shape.

My main problem today, is lack of performance upwind. My drift (heading is the same) is 5-7 degree lower than other boats, and the speed is fine above +6m/s. I’m using custom made overlapping headsail (racing) with inhaul to get headsail closer to the centerline.

BR Jesper



Back to Top
Peter-Blake View Drop Down
Admiral of the Fleet
Admiral of the Fleet
Avatar

Joined: 04 March 2008
Status: Offline
Points: 2411
Post Options Post Options   Thanks (0) Thanks(0)   Quote Peter-Blake Quote  Post ReplyReply Direct Link To This Post Posted: 25 September 2017 at 16:28
If you have the original L-Keel with lead, than you have the best keel you can get for a Hanse!
As Thomas stated the lead L-Keel is in all 5% better than the T-Steel keel. That was what J&V told me aswell in 2008 when i had a discussion with them.

In truth the diffrence is very low  between my boat (L-lead-keel) and a similar Hanse 370e with a t-steel-Keel. We sailed a long leg of about 20 miles parallel and there was nearly no diffrence in speed. OK my boat is a standard 370 and the other one was a epoxy version. Maybe thats why i was on the same speed, as the epoxy version is a lot lighter (400kg).....

Check if you have the same pointing problems on both sides. Sometimes the keel is not perfect in line. Than there is one side faster than the other.

Pointing is a question of a lot diffrent components. A wonderful sail not perfect trimmed can act like a break. Try to play with the sailshape, traveller, cunningham etc.

It is on my 370 also very important (in low winds) to get the boat running on speed first, and than head into the perfect angle. if i do not do this, than it takes a long time to get the boat on speed!

if everything does not work, than you could check the keel shape.....but do at first all other options!
Blake 370
Back to Top
Rubato View Drop Down
Admiral
Admiral
Avatar

Joined: 12 July 2006
Location: Canada
Status: Offline
Points: 1703
Post Options Post Options   Thanks (0) Thanks(0)   Quote Rubato Quote  Post ReplyReply Direct Link To This Post Posted: 25 September 2017 at 17:44
Hi Jesper
I have a few questions before I make any comment
- what size is your main (relative to the original North Dacron)?
- what size is your overlapping foresail and where do you sheet it to (I'm confused by your statement of using an innerhauler as the normal sheeting position is to the track on the side deck behind the shrouds and the shrouds will make it impossible to use an innerhauler
- what boats are you comparing yourself to?
- what wind speeds do you normally race in, is your pointing ability poor in all wind speeds?
- Do you have the sparcraft rig?
- have you followed the rig tuning guide from North?
- what tension are the various shrouds?

Steve


Edited by Rubato - 25 September 2017 at 17:49
Steve

Hanse 400e, #168
Back to Top
Mary400e View Drop Down
Sub Lieutenant
Sub Lieutenant


Joined: 05 December 2016
Location: Copenhagen
Status: Offline
Points: 17
Post Options Post Options   Thanks (0) Thanks(0)   Quote Mary400e Quote  Post ReplyReply Direct Link To This Post Posted: 26 September 2017 at 10:00

Hi Steve and others

Thanks for all your good questions/suggestions etc.

In below will I try to clarify:

Racing headsail (overlapping 37 m2 with batten), is sheeted inside the shrouds, and by using the inhaul is it possible to sheet closer to the centerline.

The main is also custom made with max size.

I have the Sparcraft rig, with high tension and pre-bend and the mast is straight (on starboard/port) up to the point where the upper shrouds ends, to make sure the forestay is tight. The rig is position in the center, before the rig is tighten.

When racing, the speed is approx. 6,8-7,2 knob in +6-7 m/s, and when tacking the speed is not below 5 knob, and we accelerate the boat before tighten in. In general, the boat perform better in higher wind +10 m/s
We have very good speed and performance on all other Wind angles (code-1 and spinnaker) when racing

Due to the Danish rating system, a large headsail (genua 1) not possible

The boat seem to be sailing with les drift on starboard, compared with port. The rudder pressure, is light on both starboard and port. Typically we are racing against fast boats like: X-40, X4, Luffe 40, IMX 38, Faurby 393

BR Jesper





Back to Top
Rubato View Drop Down
Admiral
Admiral
Avatar

Joined: 12 July 2006
Location: Canada
Status: Offline
Points: 1703
Post Options Post Options   Thanks (0) Thanks(0)   Quote Rubato Quote  Post ReplyReply Direct Link To This Post Posted: 26 September 2017 at 18:25
Hi Jesper

Have a look at this tuning guide http://www.northsails.be/RADUploads/MastSetup400.pdf
Follow it to the letter, it's super important. For the first couple of years of having the boat I followed the local advice and riggers on how the boat should be setup and the boat performed awful. Once I followed this guide using the Loos tension gauge things improved drastically. Mast rake is super important and cap shround tension is super important as well.

We regularly race in light to medium winds; 6 - 14 knots.  The boats we compete against are: J35, J36, J37, J109, X119, C&C115, Bene36.7, Express 37, Schock 35. Initially, we only had a 108% (41 sq m) jib. The sheet point was just inside and behind the shrouds and we tried to use inner haulers to bring the sheet point further inboard. Nothing worked well. We then put cabin top tracks in place (there are backing plates built in) and followed the tuning guide; this achieved a huge improvement. However, we were still not competitive under 12 knots - we could achieve speed but not enough point. Under 10 knots even the speed fell off. Then I bought a proper overlapping headsail, 138% (53 sq m), and this really helped. We still aren't pointing with the other boats when the wind is under 7-8 knots but around 9-10 we still have a lot of fun. We can carry that big foresail up to 13-14 knots. Anything above 11 and we are pointing like crazy. If the wind is down at 6 knots we might as well break out the gin and tonics. Above 14 knots we put the 105% on. Above 20 knots and we have a reef in and then above 28 we have 2 reefs in the main.

So back to your situation:
If you are sheeting inside the shrouds, your foresail is quite small and isn't overlapping much at all. In fact, a 100% jib is 38 sq meters so you are less than that. That seems quite small for wind under 12 knots. Regardless though, if the sheeting position and rig setup isn't right it will make it much worse.

That's pretty much my experience. One thing we have to accept is that the boat is big and heavy so it will never be a light wind contender. It's even more difficult to stay with the fleet downwind!

Hope that helps
Steve
Steve

Hanse 400e, #168
Back to Top
jracoffman View Drop Down
Commander
Commander
Avatar

Joined: 12 March 2013
Location: Westport, CT
Status: Offline
Points: 113
Post Options Post Options   Thanks (0) Thanks(0)   Quote jracoffman Quote  Post ReplyReply Direct Link To This Post Posted: 26 September 2017 at 19:33
I echo Steve's comments.  I would seriously consider a larger overlapping headsail for winds below 12kts, and subsequently spend time on rig tune to ensure it is perfect.
Racing with the self-tacking jib in my mind is largely a waste of time, unless it is blowing 20+kts.  Since winds in Western LIS are generally lite, I have a 155 genoa has my main foresail, I go to a 109% jib with vertical battens that I shift to at winds above 15kts.

When my rig is tuned well, I can generally point well when winds are above 10kts, but if they go lite, foregettabout it.  Have to foot off for some boat speed...

I can't imagine doing major work to the keel would be worth it from an expense and improvement perspective.


James C
Gemini, Hanse 375 #644
USA 60468
Back to Top
silversailor View Drop Down
Vice Admiral
Vice Admiral


Joined: 25 May 2005
Location: South Haven, MI
Status: Offline
Points: 940
Post Options Post Options   Thanks (0) Thanks(0)   Quote silversailor Quote  Post ReplyReply Direct Link To This Post Posted: 26 September 2017 at 22:14
This year I shifted from the North tuning guide to a much looser set up recommended by the Evolution sailmaker in Canada. Additionally, I had new sails made by Ullman Detroit (Fiberpath Race with tafetta on one side), including a new main, 135 and 155 genoas.  I use the 155 up to about 11 knots, then switch to the 135.  Above 16 knots I look to take a reef in the main. Everything improved...speed, pointing ability, light air sailing, sail shape, etc.  Don't know how much was due to the new tuning guide or the new sails.  Whatever it was I'm sticking to it.  Just got off Lake Michigan.  TW at about 10.  TWA at 90. Just pleasure sailing with my bride at a steady 7.8-8.0 knots. Doesn't get much better. We have the shoal draft (5'2") 370e.
Silversailor
South Haven, MI USA
S/V Legacy
Hanse 370e, #9
Back to Top
